8c Specifications
|
DRIVERS |
LF: 8" ALUMINIUM CONE (2x) |
| CROSSOVERS |
100 HZ & 1250 HZ, 4TH ORDER LINKWITZ-RILEY, |
| ENCLOSURE TYPE |
LF: SEALED |
| MAX LINEAR SPL @ 1M |
106 DB CONTINUOUS FROM 35 HZ UPWARDS* |
| AMPLIFIER POWER |
LF: 500 W |
| AMPLIFIER TYPE |
CLASS D, POWER FACTOR CORRECTION, HYBRID COOLING |
| MAINS INPUT VOLTAGE |
110V – 230V AC, 50 – 60 HZ |
| DIMENSIONS (H X W X D) |
485 X 270 X 380 MM (19 X 10.5 X 15 IN) |
| WEIGHT | 26 KG (57 LBS) |
| CABINET CONSTRUCTION: | SIDE AND TOP PANELS: 19 MM SOLID OAK WOOD INTERNAL CONS TRUCTION: 18MM BIRCH PLYWOOD OUTER BAFFLE: INJECTION MOULDED ABS, DAMPED |
| ANALOG INPUT | BALANCED AUDIO OVER XLR SENSITIVITY SWITCH: +4 DBU / -10 DBV PEAK INPUT LEVEL: +24 DBU (+4 DBU SETTING) |
| ANALOG OUTPUT | DSP CONTROLLED OUTPUT FOR ACTIVE SUBWOOFER |
| DIGITAL INPUT | AES3 OVER XLR LEFT / RIGHT / MONO CHANNEL SWITCH |
| DIGITAL OUTPUT | AES3 LOOP THROUGH OVER XLR |
| NETWORKING | ETHERNET OVER RJ45 |
| PROTECTION FUNCTIONS | THERMAL DC / CLIPPING |
On axis frequency and phase response*
Horizontal frequency responses**
Horizontal directivity plot**
* 1/24 octave smoothing. Anechoic chamber measurement above 100 Hz (4 π radiation). Below 100 Hz, ground plane measurement technique is used (2 π radiation) because of limitations of the anechoic chamber. Actual output and cutoff
frequency can be adjusted electronically according to the acoustics of the listening room.
** Frequency responses: 1/24 octave smoothing; directivity plot: 1/6 octave smoothing. Directivity characteristics are shown for the MF and HF sections only (100 Hz upwards) as LF radiation depends on acoustical boundary conditions.
